SPECIFICATIONS :
-
System: The Total System Consists of 2 Parts
-
A) Ultrasonic Chamber
-
B) Cooling System Consisting of Cooling Coils, Condenser
SALIENT FEATURES :
-
Imported PZT Sandwich Type Bonded at the Bottom of the Tank
-
High-Frequency Built-in MOSFET Based SMPS
-
Timer: 0 to 99 Minutes Digital Countdown with Display
-
Auto Degassing: Present 5 Minutes for Ultrasonic Tank
-
Pulse Sweep Power for Uniform Distribution of Ultrasonic Energy for Ultrasonic Tank
-
Easy to Operate and Made Up of SS 304 (16 SWG) Fabricated Tank
-
Extensive Protected Generator Circuits for Longer & Safer Operation
-
SS 304 Adjustable Basket provided. : - Drain with Ball valve will be provided.
-
SS 304 LID provided. : - Complete Instruction Manual for easy operation will be provided.
| Specification | 10 L | 20 L | 30 L |
|---|---|---|---|
| Model | Table Top | Table Top | Table Top |
| Tank Size (inches) | 12" x 10" x 6" | 18" x 12" x 6" | 14" x 14" x 10" |
| Basket Size (inches) | 11" x 9" x 5" | 17" x 11" x 5" | 12" x 12" x 8" |
| Inner Body Material | SS 304 (16 SWG thickness) with rounded corners & mirror finish | ||
| Outer Body Material | SS 304 (18 SWG thickness with matt finish) | ||
| Total Solvent Capacity | 10 ltrs | ||
| Electric Supply | 230 V AC, 50Hz, Single phase | ||
| Power Output (Ultrasonic) | 250 watt | 400 watt | 500 watt |
| Timer | 0-99 min with Digital Display of set & actual | ||
| Temperature Controller | Digital temperature controller with setting range 10°C to max 30°C, Display Resolution: 1.0°C | ||
| Cooling System | Hermetically sealed Compressor, CFC free Refrigerant | ||
| Auto Degassing | Preset for 5 Min | ||
| PSP | Pulse sweep power for uniform distribution of U/S energy | ||
| Frequency | 30 KHz ± 3 KHz | ||
| Transducers | Imported make PZT type bonded at the Bottom Side of the tank with weld bond technique | ||
| Ultrasonic Generator | Advanced latest IGBT based SMPS | ||
| Drain | ½" Drain with Ball Valve | ||
| Legs | Rubber Bush | Rubber Bush | Castor Wheels |
| Bath Liquid | Water / Solvent | ||
| STD Accessories | SS 304 Basket, Mains Cable, SS 304 Lid | ||
ORDERING INFORMATION :
| CAT. NO. | Tank Capacity (Ltr) | Tank Size (L x W x H) Inches | Overall Dimensions (L x W x H) Inches | Ultrasonic Power (Watts) |
|---|---|---|---|---|
| UCSB - 0010 | 10 | 12" x 10" x 6" | 18" x 18" x 20" | 250 |
| UCSB - 0020 | 20 | 18" x 12" x 6" | 24" x 20" x 20" | 400 |
| UCSB - 0030 | 30 | 14" x 14" x 10" | 22" x 22" x 36" | 500 |
